Industrial Electronics

Vishay has added five solenoid-based haptic actuators to its IHPT range, which come with operation licenses from Immersion Corporation. There are four sizes, from 29 x 21mm to 44 x 37mm, that can provide forces up to 120N. Not immediately obvious from the photo, each transducer us in two parts: the top left part is a separate laminated metal bar ...

Nexperia has announced 20 bipolar power transistors in 2 x 2mm DFN2020D-3 packaging, half of them automotive-qualified. The span 50 and 80V ratings, 1 to 3A currents and both npn and pnp polarities. “DFN2020D-3 packaged devices deliver an 80% reduction in board space when compared to SOT89, and a 90% reduction compared to SOT223,” according to the company. “The package ...

Onsemi has announced a 112 x 62mm power module for flying capacitor boost converters up to 1kV. It combines 1kV silicon IGBTs and 1.2kV silicon carbide diodes in the company’s F5BP package. Called NXH500B100H7F5SHG, it can handle continuous collector currents up to 210A (630A pulsed) (Tj = 175°C). Abs max power dissipation is 305W. To reducing stray inductance and thermal ...

Bourns has added six shunt resistor types its Riedon range, that it acquired in April last year when it bought Riedon Inc. Construction is with brass end-caps holding Manganin resistance elements. The latter has a temperature coefficient ~±15ppm/°C. Kelvin contacts are provided for the voltage output. Panel-mount RS resistors have values from 41.7μΩ to 20mΩ (±0.25%). There are sub-versions here: ...

Aaeon has announced 85.6 x 90mm industrial single-board computers with Intel Processor N-series (Alder Lake-N) CPUs. Called ‘UP Squared 7100’, there is a choice of Processor N97 or N100. Atom x7000E or Core i3 N-series can also be fitted to special order, and the board will also be compatible with Atom x7000RE (Amston Lake) CPUs starting from Q1 2025, said Aaeon. ...

Richardson RFPD is stocking 0402 (1005 metric) glass sandwich resistors designed to work from dc to 40GHz. Made by Kyocera AVX, and called the UBR series, they measure 1 x 0.5 x 0.5mm and have a flexible termination. “‘Flexiterm’ is a surface-mountable, automotive-qualified termination that adds an extra margin of protection against damage due to flexure during installation,” according to ...

Power factor correction with CCM (continuous conduction mode) boost converters is where ITG Electronics is aiming its latest choke family. Specifically, the series is for converters operating at between 100 and 200kHz, and up to 3.3kW. There are four parts, from 90 to 285uH, all with a 43 x 35mm footprint and standing 38mm above the PCB. They can operate ...

TDK has added 20A 500W models to its i7A range of non-isolated 1/16 brick dc-dc buck converters. All of the 20A output models, called i7A48020A033V, can operate from inputs across 28 to 60V and deliver an adjustable 3.3 to 32V – output voltage range is restricted at some input voltages, and set by an external resistor. Efficiency is up to ...

Infineon is aiming to drive motors up to 4kW with a series of integrated three-phase IGBT motor drivers. There are three: IM12B10CC1 800V 10A 2.2kW IM12B15CC1 800V 15A 3kW IM12B20EC1 800V 20A 4kW Each comes in the same 36 x 23mm DIP package and includes six 1,200V IGBTs, six anti-parallel diodes, and a protected level-shifting gate driver compatible with logic-level ...

HBK has launches what it describes as a “tactical-grade” embedded inertial navigation system in a 38 x 24 x 8.6mm 8.3g package – 18% thinner and 20% lighter than its earlier 3DMCV5. 3DM-CV7-INS, as it will be known, has 1.5°/hr gyro bias instability – which is where the tactical grade comment comes from, and is calibrated over its operating range ...
