Analog Devices has an output stage IC designed particularly for arbitrary waveform generators and power supplies. It is rather pricey, at $86 from Digikey, for example ($360 for the eval kit) but can driver up to ±40V, up to ±1A, and up to 1,800V/μs into 1nF. And, AD8460 includes a 14bit DAC with which to generate the waveforms. The technology ...
Sallen and Key filter puzzle with LTspice
I was concocting a rather silly low-pass filter design, when I remembered that Messrs Sallen and Key did it better in the 1950s, and decided to use their two-pole design to implement a Butterworth filter (thank you also Mr Butterworth). Wonderfully, there are free Sallen and Key Butterworth filter calculators on the web now – I used the one on ...
Excellent ‘free’ book on bipolar transistors (and other excellent free books too)
There is some hogwash out there, masquerading as engineering white papers, which are really just click bait to get your contact details. And there are some gems available for the same price. And, in my opinion, ‘BJT. Bipolar junction transistor application handbook‘ from Nexperia is one of the gems. The price is handing over your name, company name and email ...
Is anyone working on a pesticide sensor?
We got to hear of a citizen science project recently, where volunteers regularly sample a river and its tributaries to gather water quality information. Nitrates, for example, are measured using simple chemistry-based test kit. But pesticides need a combination of chromatography and mass spectrometry and cannot be tested in the field by an expert, let alone a citizen scientist. Part ...
One I missed: OnSemi NCV68261 ideal diode and high-side switch
YouTube presented me with a video* about a reverse polarity protection IC, On Semi’s NCV68261, which can also be an ideal diode and a load controller. And, being partial to a nice ideal diode, I thought I would take a look. It is a neat chip, called NCV68261 and measuring 2 x 2mm. Acting on the high-side, it is designed ...
Software-defined radio using a Raspberry Pi Pico
I came across a delightful design by the un-named person behind 101 Things, a blog and a YouTube channel. It is an up-to-30MHz software defined radio using a Raspberry Pi Pico for the local oscillator and… …. most of the rest of the radio. Very pleasantly, this design introduced me to a ‘Tayloe’ down-converter (after Dan Tayloe), which uses a ...
One I missed – cunning hysteric dc-dc converter
NCV30161 is a dc-dc converter intended to drive leds with a continuous current – albeit with a superimposed triangle wave. It is a buck converter – slightly up-side-down because it has its switch on the negative side. There is no output capacitor, and the inductor and the leds are in series, so they both get the same current at all ...
Raspberry Pi makes RISC-V more accessible
In choosing to put RISC-V cores on its new microcontroller – fear not, there are Arm Coretex-M33 cores too – Raspberry Pi will be helping put this architecture on the map. Proc0 and Proc1 can independently be set to be an Arm Cortex-M33 or a RISC-V core at boot Not that RISC-V is not already climbing rapidly in the instruction ...
One I missed – a whole new sort of pylon for the UK
I had no idea that National Grid has installed a new sort of pylon – T-pylons, all the way back in 2021/22 in Somerset. There are 36 of them, rated at 400kV, between Bridgwater and Loxton in Somerset, part of the 57km Hinkley Connection Project, which also has 8.5km of underground cables across the Mendip Hills (from which all existing ...
Slightly fiddly-to-find ATtiny412 information
The delightful 8pin ATtiny412 comes in a few versions, all with 4kbyte of flash and 256byte of ram, and it takes a while to dig out the following: ATtiny412-SSNR 20MHz 1.8-5.5V -40 to +105°C tape and reel ATtiny412-SSN tube or tray ATtiny412-SSFR 16MHz 2.7-5.5V -40 to +125°C tape and reel ATtiny412-SSF tube or tray
