Analogue / Linear / Mixed Signal ICs

The latest Electronics Weekly product news on analogue, linear and mixed-signal ICs.

Electronica: ASIL D vehicle battery safety monitor and pyrotechnic trigger

NXP MC33777 battery box monitor IC

NXP is aiming at ASIL D safety approval with a vehicle battery junction box controller IC, intended to fire the pyrotechnic disconnect switch during a serious fault, as well as report faults over a serial bus. MC33777A, as it will be known, redundantly measures currents, voltages and temperatures, then deduces situations – a short circuit or a crash, for example ...

1MHz 80-800A core-less current sensors in TSSOP and SOIC

Allegro CT456 current sensor app

Allegro MicroSystems had introduced 1MHz bandwidth current sensors that can measure hundreds of amps – the first fruit of its acquisition of Crocus Technologies. The technology is tunneling magnetoresistance, and the sensors are intended to sit over the current-carrying PCB track to be measured. Output is a voltage linearly proportional to the current, responding within 300ns. There are two base ...

IC promises UWB radar for smart home automation

NXP UWB radar application image

NXP has combined short-range 6 – 8.5GHz UWB radar, secure ranging and angle-of-arrival processing on a single chip. Called SR250, it is for “a world that anticipates and automates, enabling a variety of new user experiences based on location, presence or motion detection across consumer or industrial IoT applications”, claimed the company. It is said to support 3D angle-of-arrival and ...

Automotive CXPI interface has GPIO, ADC and PWMs

Toshiba VQFN package

Toshiba is developing an interface IC for the automotive CXPI (clock extension peripheral interface) bus whose hardware logic “can control data communication by CXPI protocol and GPIO, eliminating the need for dedicated software development”, according to the company. Not a lot more has been revealed about the function of the IC, called TB9033FTG, except that it has 16 GPIO pins, ...

All-constellation RTK GNSS modules

Rutronik Unicore GNSS UM980

Distributor Rutronik has added three surface-mount RTK-enhanced GNSS modules from Unicore to its portfolio. RTK – ‘real time kinematics’ – is a service that increases the accuracy of satellite navigation systems. UM982 GPS L1/L2/L5 BDS B1I/B2I/B3I GLONASS G1/G2 Galileo E1/E5a/E5b QZSS L1/L2/L5 SBAS 16 x 21 x 2.6mm UM980 BDS B1I/B2I/B3I/B1C/B2a/B2b GPS L1/L2/L5 GLONASS L1/L2 Galileo E1/E5a/E5b QZSS L1/L2/L5 SBAS ...

12-channel LED driver for signage and displays

Diodes AL58263 led driver block

Diodes has introduced a 12-channel constant-current LED driver arranged as four channels of RGB. AL58221 has open-drain outputs that can sink up to 60mA and withstand 24V. Maximum red green and blue currents are set with three resistors, then the individual channels are digitally-modulated to set their brightness. To reduce flicker, adaptive pulse density modulation is used, with diodes claiming ...

Mains 3A brush-less dc motor driver shrugs off 600V surges

Toshiba TPD4165K 3A 600V bldc motor driver block app

Toshiba is aiming at air conditioners, air purifiers and pumps with an IGBT-based brush-less dc motor driver, suitable for sine-wave generation, in a ~13 x 33mm through-hole HDIP30 package. TPD4165K, as it will be know, can handle a maximum output of 3A, compared with 2A for the company’s earlier TPD4163K or TPD4164K. Absolute maximum input voltage has been raised to ...

Automotive ideal diode protects against -65V

Diodes AP74700Q ideal diode controller app

It seems to be Ideal Diode Week at Electronics Weekly (here and here) as Diodes is also promoting one, this time an ideal diode that can cope with ±65V on its input and drops only 20mV when conducting. The automotive-compliant AP74700Q operates down to 3.2V (or 3.9V at start-up) to allow for cold cranking of a vehicle engine. Inside, a ...

1.5A ideal diode and reverse polarity protection in 2.1 x 1.25mm

Nexperia NID5100 ideal diode block

Nexperia has put an ideal diode, including its p-channel mosfet, and reverse polarity protection, in a 2.1 x 1.25 x 0.95mm TSSOP6 package. Called NID5100, it is aimed at industrial and consumer applications, and has an automotive-qualified cousin named NID5100-Q100. “NID5100 supports ‘OR-ing’ multiple power supplies while retaining reverse polarity protection and provides fast response time for smooth power transfer,” ...

Automotive voltage regulator with reset and watchdog

Infineon TLS820F3ELV50 linear regulator

Infineon has introduced six automotive linear regulators, protected against 40 or 45V, and supplying 3.3 or 5V at up 500mA, some with enable, watchdog or reset circuits (see the table below). Picking the TLS820F3ELV50 as an example, it has an input range of 3 to 42V (45V abs max) and outputs 5V ±2% at up to 200mA. “These regulators are ...
