3A bipolar transistors in 2x2mm DFN2020D-3 package

Nexperia has announced 20 bipolar power transistors in 2 x 2mm DFN2020D-3 packaging, half of them automotive-qualified.

Nexperia DFN2020D-3 package

The span 50 and 80V ratings, 1 to 3A currents and both npn and pnp polarities.

“DFN2020D-3 packaged devices deliver an 80% reduction in board space when compared to SOT89, and a 90% reduction compared to SOT223,” according to the company. “The package also features side-wettable flanks to enable automated optical inspection of solder joints.”


SOT1061D is the other name for this package. To allow for side wetting, it has a 2.5 x 2.1 footprint on the PCB, which is 5.25mm2, compared with 4.83mm2 for the non-side-wetting SOT1061/DFN2020-3.


pnp
npn
Vceo max Ic max Gain Low-sat Part
p -50V -3A 200 – 450 y PBSS5350PAS-Q​
p -50 -2 200
min
y PBSS5250PAS-Q​
n 50 3 300 – 700 y PBSS4350PAS-Q​
n 80 1 63 – 250 BC56PAST-Q
n 80 1 63 – 160 BC56-10PAST-Q
n 80 1 100 – 250 BC56-16PAST-Q
p -80 -1 63 – 250 BC53PAST-Q
p -80 -1 63 – 160 BC53-10PAST-Q
p -80 -1 100 – 250 BC53-16PAST-Q
p -80 -1 No

data

BSR33PAS-Q​

Notes:
This list has been transcribed and may contain errors
BC56.. types are the npn compliments to BC53… types.
‘-Q’ suffix indicates automotive qualified. Delete for industrial parts.

Of these, the company highlights its PBSS5350PAS-Q pnp 50V, 3A low saturation voltage transistor.

This will drop only 320mV max at 2A with 100mA base drive (25°C) or 390mV max at 3A with 300mA drive. Saturation resistance is 135mΩ max (90mΩ typ).

Find the PBSS5350PAS-Q data sheet here

Nexperia’s DFN2020D-3/SOT1061D package data sheet
